LC Multimode Fiber Optic Attenuators
Fiber optic attenuators are used in the fiber optic communications to reduce the optical fiber power at a certain level, the most commonly used type is female to male plug type fiber optic attenuator, it has the optical fiber connector at one side and the other side is a female type fiber optic adapter, fiber optic attenuator name is based on the connector type and the attenuation level. LC 5dB fiber optic attenuator means this attenuator uses LC fiber optic connector and it can reduce the optical fiber power level by 5dB. Commonly used attenuation range is from 1dB to 20dB. |
Note : All fiber attenuators are Premium, Zirconia Sleeve, Doped attenuation fiber type and are well suited for fiber amplifier, DWDM and telecommunications equipment. |
Optical Attenuator Type |
Part Number |
Price (USD) |
LC Multimode 850-1310nm 62.5/125um Fiber Optic Attenuator 5dB Optical attenuation |
DFA-1532-053 |
$34.95 |
LC Multimode 850-1310nm 62.5/125um Fiber Optic Attenuator 10dB Optical attenuation |
DFA-1532-103 |
$34.95 |
LC Multimode 850-1310nm 62.5/125um Fiber Optic Attenuator 15dB Optical attenuation |
DFA-1532-153 |
$34.95 |
LC Multimode 850-1310nm 62.5/125um Fiber Optic Attenuator 20dB Optical attenuation |
DFA-1532-203 |
$34.95 |
|
|
|
LC Multimode 850-1310nm 50/125um Fiber Optic Attenuator 5dB Optical attenuation |
DFA-1532-052 |
$34.95 |
LC Multimode 850-1310nm 50/125um Fiber Optic Attenuator 10dB Optical attenuation |
DFA-1532-102 |
$34.95 |
LC Multimode 850-1310nm 50/125um Fiber Optic Attenuator 15dB Optical attenuation |
DFA-1532-152 |
$34.95 |
LC Multimode 850-1310nm 50/125um Fiber Optic Attenuator 20dB Optical attenuation |
DFA-1532-202 |
$34.95 |
Attenuation Value 1dB ~ 30dB |
|
Operating Wavelength 850 ~ 1310nm 62.5 or 50um Multimode |
|
Premium |
|
Return Loss |
UPC >55dB |
APC >65dB |
|
Attenuation Accuracy |
1 ~ 7 dB ±0.5dB |
8 ~ 12 dB ±0.7dB |
|
13 ~ 17 dB ±1.0dB |
|
18 ~ 25 dB ±1.3dB |
|
Maximum Optical Input Power 1000mW |
|
Polarization Dependent Loss ≤0.1dB |
|
Operating Temperature Range -40 to 75 |
|
Storage Temperature Range -40 to 85 |
|
Humidity 95%RH |
